D-subminiature Metal Shell
Wire Wrap
Basic D Series
? Reliable wire wrap termination.
?
?
Two contact lengths: .375" or .585".
.025" square contact tails.
Materials
?
?
Contact Material: Copper alloy (machined).
Contact Plating: Gold flash or 30μin. gold. All over nickel.
.375 (9.53) or
.585 (14.86)
.200 (5.08) REF.
Ordering Information
Wire Wrap Plugs
.375 " Tail Length
Zinc-Plated Shell with Yellow Chromate Finish
4
Mounting Holes
4-40 Clinch Nuts
Dual Float Bushings
Positions
9
15
25
37
50
Gold Flash 30μin. Gold
DE-9P-F179 DE-9P-F179-30
DA-15P-F179 DA-15P-F179-30
DB-25P-F179 DB-25P-F179-30
DC-37P-F179 DC-37P-F179-30
DD-50P-F179 DD-50P-F179-30
Gold Flash 30μin. Gold
DEE-9P-F179 DEE-9P-F179-30
DAE-15P-F179 DAE-15P-F179-30
DBE-25P-F179 DBE-25P-F179-30
DCE-37P-F179 DCE-37P-F179-30
DDE-50P-F179 DDE-50P-F179-30
Gold Flash 30μin. Gold
DEY-9P-F179 DEY-9P-F179-30
DAY-15P-F179 DAY-15P-F179-30
DBY-25P-F179 DBY-25P-F179-30
DCY-37P-F179 DCY-37P-F179-30
DDY-50P-F179 DDY-50P-F179-30
Tin-Plated Shell with Grounding Indents
Mounting Holes
4-40 Clinch Nuts
Dual Float Bushings
Positions
9
15
25
37
50
Gold Flash 30μin. Gold
DE-9PTI-F179 DE-9PTI-F179-30
DA-15PTI-F179 DA-15PTI-F179-30
DB-25PTI-F179 DB-25PTI-F179-30
DC-37PTI-F179 DC-37PTI-F179-30
DD-50PTI-F179 DD-50PTI-F179-30
Gold Flash 30μin. Gold
DEE-9PTI-F179 DEE-9PTI-F179-30
DAE-15PTI-F179 DAE-15PTI-F179-30
DBE-25PTI-F179 DBE-25PTI-F179-30
DCE-37PTI-F179 DCE-37PTI-F179-30
DDE-50PTI-F179 DDE-50PTI-F179-30
Gold Flash 30μin. Gold
DEY-9PTI-F179 DEY-9PTI-F179-30
DAY-15PTI-F179 DAY-15PTI-F179-30
DBY-25PTI-F179 DBY-25PTI-F179-30
DCY-37PTI-F179 DCY-37PTI-F179-30
DDY-50PTI-F179 DDY-50PTI-F179-30
4-45
Call Toll Free: 1 (800) 323-9612
